Vacuum Glass Lifter 50kg Manual Lifting Suction Lifting Aluminum Lifting Plate

Cheap Price 400kg 600kg 800g 1000kg Glass Vacuum LifterPLK LIFT suction caps are specially design for handling different kinds of heavy plate, board and glass, useful for installing steel board, glass wall, moving such as granite, marble. Model GL-SC-400GL-SC-600GL-SC-800GL-SC-1000Lifting Capacitykg4006008001000Cu

Featured Products




Cheap Price 400kg 600kg 800g 1000kg Glass Vacuum Lifter
PLK LIFT suction caps are specially design for handling different kinds of heavy plate, board and glass, useful for installing steel board, glass wall, moving such as granite, marble.

Model GL-SC-400GL-SC-600GL-SC-800GL-SC-1000
Lifting Capacitykg4006008001000
Cup Qty/46810
Single Cup Sizemm300300300300
Single Cup Lifting Capacitykg100100100100
Rotation/360°manual rotate
Tilting/90° manual
VolteVDC12
ChargerVAC220/110
Weightkg7090100110
Sucker Frame Sizemm850*750*3001800*900*3001760*1460*3001900*1600*300
Extension Bar Lengthmm500
Control System/Integrated Control Cabinet and Wired Remote Control
Vacuum Glass Lifter 50kg Manual Plate Lifter Aluminum Suction Lifter


Features & Advantages:

1.Sealed cover for components protection,safe and reliable. Usually cooperated with bridge crane to use in glass deep processing and handling job, or with cantilever crane to use in glass curtain wall installation job .
2.Adjustable type, can be changed the position of the suction cup to absorb glass of different shapes and sizes (also can be customized according to the glass size)
3.Manually rotated 360° in the vertical side, and manually rotated 90° in the horizontal side, but taking and releasing by electric
4.Adopt American THOMAS vacuum pump and high quality maintenance-free battery, no need the air source or power supply during use.
5.Japan Panasonic digital display vacuum pressure switch , battery fuel gauge, clearly monitor the safty use.
6.With vacuum pressure auto supply system, during handling glass, ensure the whole vacuum system maintained at a relatively constant safety pressure value
7.Equipped with the power-cut but pressure-keeping device and alarm device. If power failure accidently,the pressure-keepping function can extend the handling time and make the use safer.
8.Equipped with 12V backup battery, can be replaced in time to ensure the progress of the project.

Offer OEM & ODM service,according to different materials size and weight.
Please inform us the materials you want to lift,as well as size and weight to get a proper proposal.
Vacuum Glass Lifter 50kg Manual Plate Lifter Aluminum Suction Lifter
Vacuum Glass Lifter 50kg Manual Plate Lifter Aluminum Suction Lifter
