2.2kw 380V (2200W 400V) Universal Vector Control Inverter AC Inverter Power Inverter Frequency Converter

 EC5000 GENERAL VECTOR CONTROL SERIES Production IntroductionEC5000 is the company\'s independently developed flagship product with high cost performance, which absorbs advanced international frequency converter technology. It is a mature product that has been continuously improved for more than a decade and features p

Featured Products


2.2kw 380V (2200W 400V) General Use Vector Control Inverter AC Inverter Power Inverter Frequency Inverter




EC5000
GENERAL VECTOR CONTROL SERIES



Production Introduction

EC5000 is the company's independently developed flagship product with high cost performance, which absorbs advanced international frequency converter technology. It is a mature product that has been continuously improved for more than a decade and features plenty of industry application cases.
Power Ranger
220V level : 0.4-132KW          380V level : 0.75-350KW
Technical Feature
1,VTC current vector control algorithm realizes high starting torque and stable low-speed torque output.
2,It integrates plenty of industry application software functions to facilitate various field control requirements.
3,Sufficient I / O interface, with 8 sections of speed input, 2 channels of analog input, 2 channels of relay output and 2 channels of open circuit collector output.
4,Design, test and production strictly complies with international standard, strengthen the optimized design of heat dissipation, overload capacity, electromagnetic compatibility, etc., with built-in input wave filter for the whole series of products.
5,The product is equipped with standard RS485 serial communication interface and adopts standard Modbus communication protocol.
6,Provide optional digital Chinese interface LCD operation keyboard to realize convenient and quick operation. The keyboard has parameter copy function and Chinese interface LCD keyboard to realize convenient and quick debugging for users.
7,With automatic current amplitude limiting ensures no-trip operation.
8The whole series of products are made of highly flame retardant materials and high reliability main circuit on-link mode to ensure the safety of product operation.

Application Industry
Application
Packing machinery, Automatic production line, Textile machinery, Fan and water pump, Food machinery, Medical machinery, Municipal engineering, Hoisting machinery, Light industrial machinery, Woodworking machinery, Pharmaceutical machinery, Wire drawing machine, Textile and chemical fiber

Technical Specifications
2.2kw 380V (2200W 400V) General Use Vector Control Inverter AC Inverter Power Inverter Frequency Inverter


Operation and display
2.2kw 380V (2200W 400V) General Use Vector Control Inverter AC Inverter Power Inverter Frequency Inverter
2.2kw 380V (2200W 400V) General Use Vector Control Inverter AC Inverter Power Inverter Frequency Inverter



Note: * The above is a conventional model, 220V can be customized to 132G(KW)



Contact us

Please feel free to give your inquiry in the form below We will reply you in 24 hours
